KEY FEATURES
· 10-30% Additional Power Generation30 years lifespan brings 10-30% additional power
· ZERO|LID (Light Induced Degradation)N-type solar cell has no LID naturally whichcan increase power generation
· Excellent low temperature coefficient, generating1%-2% more electricity in high-temperature areas.
· Module can bear snow loads up to 5400Paand wind loads up to 2400Pa
· Manufactured according to and certified international I Qualityand Environment Management System
· Using advanced low reflection and high light transmission glassand cell sheet surface cutting technology, in the weak lightenvironment can also play a good performance.
Certificates
· IEC61215,IEC61730,CQC、CE、TUV、UKCA
· ISO9001:2015
· ISO14001:2015
· ISO45001:2018
Electrical Characteristics
Model
| NS-700MH-132 | NS-705MH-132 | NS-710MH-132 | NS-715MH-132 | NS-720MH-132 |
Maximum Power at STC(Pmax) | 700W | 705W | 710W | 715W | 720W |
Optimum Operating Voltage (Vmp) | 41.29V | 41.44V | 41.59V | 41.74V | 41.89V |
Optimum Operating Current (Imp) | 16.96A | 17.02A | 17.08A | 17.13A | 17.19A |
Open-Circuit Voltage (Voc) | 49.68V | 49.76V | 49.84V | 49.92V | 50.00V |
Short-Circuit Current (Isc) | 17.61A | 17.71A | 17.81A | 17.90A | 18.00A |
Solar Cell Efficiency (%) | 24.29 | 24.46 | 24.63 | 24.81 | 24.98 |
Solar Module Efficiency (%) | 22.53 | 22.69 | 22.85 | 23.01 | 23.17 |
Operating Temperature | -40 to 85℃ |
Maximum System Voltage | DC1500V |
Maximum Series Fuse Rating | 30A |
Power Tolerance | 0~+3% |
STC | Irradiance 1000W/㎡,Modules Temperature 25℃,AM=1.5 |
Temperature Coefficient
| NOCT | 45℃±2℃ |
| Temperature Coefficient of Pmax | -0.29%/℃ |
| Temperature Coefficient of VOC | -0.25%/℃ |
| Temperature Coefficient of ISC | 0.045%/℃ |
Mechanical Characteristics
| No.of cells | 132(6×11+6×11) |
| Dimensions | 2384mm*1303mm*30mm |
| Weight | 38.7kg ±3% |
| Front Glass | 2mm + 2mm Tempered glass |
| Back Glass | 2mm Heat Strengtdened Glass |
| Junction box | IP68, tdree diodes |
| Connector | Plug and socket |
| Output cables | PV 4.0mm² |
| 1*40'HQ | 37 pcs/Pallet, 666pcs/ 40'HQ; |
